CAN
PSCAN Plus
₹7,000
The PSCAN Plus is a commercial‑grade isolated USB to CAN interface built for professional use in automotive, industrial, and laboratory environments. It supports classic CAN 2.0A/B with bitrates up to 1 Mbps, providing low‑latency and reliable communication for demanding…
Also known as USB CAN analyzer, USB-CAN adapter, CAN bus analyzer
Bitrate5 kbps to 1 Mbps
IsolationYes
InterfaceUSB 2.0 High Speed
Timestamp Resolution1 μs
Supported Operating SystemsWindows 10/11, macOS 11+, Linux
Dimensions65 x 40 x 26 mm
1-year warranty
7-day returns
Software, drivers and documentation are in the Downloads tab below
The PSCAN Plus is a commercial‑grade isolated USB to CAN interface built for professional use in automotive, industrial, and laboratory environments. It supports classic CAN 2.0A/B with bitrates up to 1 Mbps, providing low‑latency and reliable communication for demanding applications such as ECU development, production testing, and long‑term logging. The galvanically isolated CAN interface, robust bus fault protection, and higher common‑mode voltage rating help protect both the host PC and connected equipment in harsh environments. PSCAN Plus comes with an integrated cable, simplifying installation and allowing flexible placement of the interface on benches or inside vehicles. Combined with cross‑platform software support, it offers a ready‑to‑deploy solution for commercial and professional CAN workflows.
InterfaceUSB 2.0 High Speed
CAN StandardsCAN 2.0A/B, ISO 11898
Bitrate5 kbps to 1 Mbps
Messages/SecondUp to 8400
Error DetectionSupported
Silent ModeSupported
Timestamp Resolution1 μs
IsolationYes
Power SupplyUSB Power (5V)
Isolation voltage±2500V
Bus Fault Protection±72V
Dimensions65 x 40 x 26 mm
Supported Operating SystemsWindows 10/11, macOS 11+, Linux
Documentation
1 itemPSCAN Devices Datasheet
Data sheet for the PSCAN models - Plus, Air, Nano
All · v1.1.0 · 263KB
Download
Drivers
2 itemsPSCAN Native API Library
Native libraries for interacting with PSCAN devices: Windows DLL, macOS dylib, and Linux SO files.
Windows, Mac, Linux · v0.2.0
Request access
PSCAN Python Library
Windows, Mac, Linux · v0.1.9
Download
Software
3 itemsPSCAN CLI tools
Various command line tools to access PSCAN devices
PSCAN Studio
A CAN bus monitoring tool built on BUSMASTER, with significant enhancements and added features.
Windows · v1.2.9 · 19MB
Request access
PSCAN Manager
PSCAN Manager used to update the firmware and many more
- CAN support up to 1 Mbps
- Backward compatible with CAN 2.0
- Enhanced galvanic isolation
- Professional-grade build quality
- Extended temperature range
- Free software included
- Cross-platform Support
- Support for Linux SocketCAN
- Python, Rust, C++, Labview, MATLAB libraries
Can I get service if the cable is damaged?
Yes, service support is available if the cable gets damaged.
Is the cable easy to replace?
Yes, the cable is designed to be easily replaceable without needing special tools.
Is Linux SocketCAN support available?
Yes, Linux SocketCAN support is available for all PSCAN devices, Please send an email to our support team with your product details and Linux support requirement.
Which libraries are available for PSCAN Plus?
PSCAN Plus supports software libraries and APIs for most of use cases. Please check the download section or contact support for the latest available library package
